SKU: SW-Series
Instantly create temporary conveyor lines in your shipping & receiving, packing or assembly lines with our gravity skatewheel conveyors. Designed to expand, contract and move easily, our gravity skatewheel conveyor is a self tracking, gravity skatewheel conveyor that has a per linear foot capacity of 100-pounds. This conveyor is engineered to handle multi-sized cartons in low to medium volume applications.
Optimize floor space as this conveyor can be compacted for storage when not in use. Free spinning skate wheels (nylon wheels with roller bearings) on the conveyor make the unit very portable. Multiple conveyors can be combined for additional length with the included latching brackets. Adjustable inner legs vary height to achieve gravity flow.
Features
- Load capacity: 100-lbs/ft
- Adjustable height from 28" – 44"
- 5" axle centers
- Heavy duty black nylon wheels
- 4" diameter locking casters
- Package end stop included
- Options: steel skate wheels (special order)
- Warranty: 1-year
- Unit ships via LTL freight only. Call for freight rates
- SKU: AW-24-20-10L
- Manufacturer: Hytrol
Gravity skatewheel conveyor is ideally used to convey lightweight packages or when operation requires lightweight sections. Skatewheel is useful in setting up temporary conveyor lines in warehousing activities, shipping departments, assembly areas, etc. Loads should be even and smooth for best performance. A minimum of 10 wheels under each product is required for smooth rolling.
